Magento Tutorial – How to Install Magento Modules and extensions manually

How to use Magento Connect to install Modules and Extensions

magento-modulesMagento has the built-in functionality to automatically install additional modules for your online store. Basically all you need is the extension’s key and the script will install it for you in just a few clicks. In this tutorial we will clarify in details how to install additional modules/extensions for Magento via Magento Connect. Also, we will afford instructions how to upgrade existing modules/extensions for Magento.

First, you need to log in to the Magento administrator area. Then go to System -> Magento Connect -> Magento Connect Manager.

Magento Connect Manager

A new page will open for the Magento Connect Manager and you will be asked to provide your administrative credentials again.


Magento Connect Manager log in

Once logged in you will see 2 sections: Extensions and Settings. It is recommended to verify the options chosen in the Settings section first.

Magento Connect Manager Settings

In the Settings section there are several options you can configure, but leaving the default values is recommended.

Magento Connect Manager Settings: stable vs Beta

The Preferred State option controls the state of the extensions you install. There are 3 states – Stable, Beta and Alpha. For live sites the Stable option is recommended. Setting it to Beta/Alpha gives you the opportunity to check the latest versions of the extensions, but this is usually not recommended as extensions in Beta and particularly Alpha state might have bugs and could disrupt the functionality of your online store.


It is of complete importance to create a backup before downloading extensions or extension upgrades. This way if an issue occurs after downloading and installing an extension you can revert the changes by restoring a working backup.

Once you create the backup you can access Magento Connect Manager -> Extensions tab. Click the link to Magento Connect.

This will open a new window for Magento Connect and let you browse the available extensions. There is a search functionality included and modules are separated in different categories.

Magento Manager Extension categories

There are various extensions. Some are free and others are paid. In each case the download from Magento Connect needs registration in order to get the extension key. Instructions may vary depending on the exact extension.

magento-extensionsOnce you have chosen an extension click the Install Now button and choose the Magento Connect version matching your current Magento version. If you are using Magento 1.5 or newer, you need to select version 2.0, otherwise leave Magento Connect 1.0. Read the extension license agreement and then check the box for “I agree to the extension license agreement”. Finally, click the Get Extension Key button.

Magento Connect Manager Get Extension Key

You will be provided with the Extension key:

 Magento Connect Manager License agreement

This is the key that you need to copy and paste in your Magento Connect area. Then click Install and then Proceed.

Magento Connect Manager Extension Key

The new extension will be automatically downloaded and installed. If there is a problem with the installation, there will be information about it so that you know what should be done to resolve it. After the extension is properly installed a screen for a successful installation will appear:

Magento Connect Manager Installation Console

Once the extension is installed it is significant to go back to Magento admin and adjust its options according to your needs. Also ensure that your online store is properly functioning and there are no errors.

How to upgrade an existing Magento Extension

In order to check for upgrades for the Magento extensions you can follow the instructions below.

Log in to the Magento admin area -> System -> Magento Connect -> Magento Connect Manager. On the Extensions Tab click on Check for Upgrades .

Magento Connect Manager check for upgrades

The Magento Connect manager will automatically connect to the server and check for available upgrades. If you have an extension that has a published upgrade they will be colored in yellow and you will be able to apply the upgrade to your Magento module. Note that it is again extremely important to backup your Magento online store before applying the upgrade. From the Actions drop-down menu you will be able to select the desired upgrade version. Then click Commit Changes to proceed with the upgrade.

Magento Extension Upgrade

The chosen upgrade will be automatically downloaded and applied.

Once the extension is upgraded you can refresh the page via the Refresh button. Then check the current status of your extension. You will find the yellow color has been removed for your Upgraded Extension and the Installed column has changed to the version number you just installed.

You can now click Return to Admin and check if any new Configuration Settings for your Extension are available. Also ensure that your online store is properly functioning and there are no errors.
